Step1: Product
EVVO KBPC2510
Image shown is a representation only
Manufacturer
Manufacturer No
KBPC2510
Package
4-Square, KBPC
Packaging
Box
Description
25A SINGLE - PHASE SILICON BRIDG
Detailed Description
Bridge Rectifier Single Phase Standard 1000 V Through Hole KBPC
DataSheet
Series
*
Packaging
Box
Diode Type
Single Phase
Technology
Standard
Part Status
Active
Manufacturer
EVVO
Mounting Type
Through Hole
Package / Case
4-Square, KBPC
Operating Temperature
-40°C ~ 150°C
Supplier Device Package
KBPC
Voltage - Peak Reverse (Max)
1000 V
Current - Reverse Leakage @ Vr
0.1 mA @ 1000 V
Current - Average Rectified (Io)
25 A
Voltage - Forward (Vf) (Max) @ If
1.1 V @ 12.5 A
| Attribute | Value |
|---|---|
| Series | * |
| Packaging | Box |
| Diode Type | Single Phase |
| Technology | Standard |
| Part Status | Active |
| Manufacturer | EVVO |
| Mounting Type | Through Hole |
| Package / Case | 4-Square, KBPC |
| Operating Temperature | -40°C ~ 150°C |
| Supplier Device Package | KBPC |
| Voltage - Peak Reverse (Max) | 1000 V |
| Current - Reverse Leakage @ Vr | 0.1 mA @ 1000 V |
| Current - Average Rectified (Io) | 25 A |
| Voltage - Forward (Vf) (Max) @ If | 1.1 V @ 12.5 A |
