Step1: Product
ept, inc 243-22310-15
Image shown is a representation only
Manufacturer
Manufacturer No
243-22310-15
Packaging
Tube
Description
MALE TYPE B22 154PINS PRESS-FIT
Detailed Description
154 Position Header, Male Pins Connector 0.079" (2.00mm) Through Hole
DataSheet
Pitch
0.079" (2.00mm)
Series
243
Features
Upper Shield
Packaging
Tube
Part Status
Active
Termination
Press-Fit
Manufacturer
ept, inc
Mounting Type
Through Hole
Connector Type
Header, Male Pins
Contact Finish
Gold
Number of Rows
5
Connector Style
B 22
Connector Usage
Backplane
Number of Positions
154
Current Rating (Amps)
1.5 A
Operating Temperature
-55°C ~ 125°C
Contact Finish Thickness
7.90µin (0.200µm)
Number of Positions Loaded
All
| Attribute | Value |
|---|---|
| Pitch | 0.079" (2.00mm) |
| Series | 243 |
| Features | Upper Shield |
| Packaging | Tube |
| Part Status | Active |
| Termination | Press-Fit |
| Manufacturer | ept, inc |
| Mounting Type | Through Hole |
| Connector Type | Header, Male Pins |
| Contact Finish | Gold |
| Number of Rows | 5 |
| Connector Style | B 22 |
| Connector Usage | Backplane |
| Number of Positions | 154 |
| Current Rating (Amps) | 1.5 A |
| Operating Temperature | -55°C ~ 125°C |
| Contact Finish Thickness | 7.90µin (0.200µm) |
| Number of Positions Loaded | All |
