Step1: Product
EDAC Inc. 627-36W4624-1NA
Image shown is a representation only
Manufacturer
Manufacturer No
627-36W4624-1NA
Packaging
Tray
Description
CONN D-SUB PLG 36POS PNL MT SLDR
Detailed Description
36 (32 + 4 Power) Position D-Sub, Combo Plug, Male Pins Connector
Datasheet
Mfr
EDAC Inc.
Color
Black
Series
627-C
Features
Grounding Indents, Shielded
Packaging
Tray
Termination
Solder
Contact Type
Signal and Power
Mounting Type
Panel Mount, Through Hole
Connector Type
Plug, Male Pins
Contact Finish
Gold
Flange Feature
Board Side (M3)
Number of Rows
3
Voltage Rating
125V
Connector Style
D-Sub, Combo
Contact Material
Copper Alloy
Base Product Number
627-36W
Dielectric Material
Polyester Thermoplastic
Number of Positions
36 (32 + 4 Power)
Current Rating (Amps)
5A, 10A
Operating Temperature
-55°C ~ 125°C
Shell Material, Finish
Steel, Nickel Plated
Contact Finish Thickness
30.0µin (0.76µm)
Material Flammability Rating
UL94 V-0
Shell Size, Connector Layout
5 (DD, D) - 36W4
| Attribute | Value |
|---|---|
| Mfr | EDAC Inc. |
| Color | Black |
| Series | 627-C |
| Features | Grounding Indents, Shielded |
| Packaging | Tray |
| Termination | Solder |
| Contact Type | Signal and Power |
| Mounting Type | Panel Mount, Through Hole |
| Connector Type | Plug, Male Pins |
| Contact Finish | Gold |
| Flange Feature | Board Side (M3) |
| Number of Rows | 3 |
| Voltage Rating | 125V |
| Connector Style | D-Sub, Combo |
| Contact Material | Copper Alloy |
| Base Product Number | 627-36W |
| Dielectric Material | Polyester Thermoplastic |
| Number of Positions | 36 (32 + 4 Power) |
| Current Rating (Amps) | 5A, 10A |
| Operating Temperature | -55°C ~ 125°C |
| Shell Material, Finish | Steel, Nickel Plated |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Material Flammability Rating | UL94 V-0 |
| Shell Size, Connector Layout | 5 (DD, D) - 36W4 |
