Step1: Product
Diodes Incorporated PI5USB216XUAEX
Image shown is a representation only
Manufacturer
Manufacturer No
PI5USB216XUAEX
Quantity
8
Availability
In Stock
Package
12-XFQFN
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
USB2 Eqx X2-QFN1616-12 T&R 3.5K
Detailed Description
Buffer, ReDriver 2 Channel 480Mbps 12-STQFN (1.6x1.6)
DataSheet
Type
Buffer, ReDriver
Input
2-Wire Bus
Output
2-Wire Bus
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Part Status
Active
Applications
USB
Manufacturer
Diodes Incorporated
Mounting Type
Surface Mount
Package / Case
12-XFQFN
Data Rate (Max)
480Mbps
Current - Supply
22mA
Voltage - Supply
2.3V ~ 5.5V
Number of Channels
2
Capacitance - Input
2.4 pF
Signal Conditioning
Input Equalization, Output Pre-Emphasis
Operating Temperature
-40°C ~ 85°C (TA)
Supplier Device Package
12-STQFN (1.6x1.6)
| Attribute | Value |
|---|---|
| Type | Buffer, ReDriver |
| Input | 2-Wire Bus |
| Output | 2-Wire Bus |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Part Status | Active |
| Applications | USB |
| Manufacturer | Diodes Incorporated |
| Mounting Type | Surface Mount |
| Package / Case | 12-XFQFN |
| Data Rate (Max) | 480Mbps |
| Current - Supply | 22mA |
| Voltage - Supply | 2.3V ~ 5.5V |
| Number of Channels | 2 |
| Capacitance - Input | 2.4 pF |
| Signal Conditioning | Input Equalization, Output Pre-Emphasis |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Supplier Device Package | 12-STQFN (1.6x1.6) |
