Step1: Product
Diodes Incorporated MMBZ9V1ALA-7
Image shown is a representation only
Manufacturer
Manufacturer No
MMBZ9V1ALA-7
Package
TO-236-3, SC-59, SOT-23-3
Packaging
Tape & Reel (TR)
Description
TVS DIODE 6VWM 14VC SOT233
Detailed Description
14V Clamp 1.7A Ipp Tvs Diode Surface Mount SOT-23-3
Mfr
Diodes Incorporated
Type
Zener
Packaging
Tape & Reel (TR)
Part Status
Active
Applications
General Purpose
Mounting Type
Surface Mount
Package / Case
TO-236-3, SC-59, SOT-23-3
Power - Peak Pulse
24W
Operating Temperature
-55°C ~ 150°C (TJ)
Power Line Protection
No
Supplier Device Package
SOT-23-3
Unidirectional Channels
2
Voltage - Breakdown (Min)
8.65V
Voltage - Clamping (Max) @ Ipp
14V
Voltage - Reverse Standoff (Typ)
6V
Current - Peak Pulse (10/1000µs)
1.7A
| Attribute | Value |
|---|---|
| Mfr | Diodes Incorporated |
| Type | Zener |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Applications | General Purpose |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Power - Peak Pulse | 24W |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Power Line Protection | No |
| Supplier Device Package | SOT-23-3 |
| Unidirectional Channels | 2 |
| Voltage - Breakdown (Min) | 8.65V |
| Voltage - Clamping (Max) @ Ipp | 14V |
| Voltage - Reverse Standoff (Typ) | 6V |
| Current - Peak Pulse (10/1000µs) | 1.7A |
