Step1: Product
Dialight 59912A0147IRF
Image shown is a representation only
Manufacturer
Manufacturer No
59912A0147IRF
Package
1206 (3216 Metric)
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
599 SERIES MICROLED SMD LED, 120
Detailed Description
Infrared (IR) Emitter 850nm 1.36V 100mA 1mW/sr @ 100mA 140° 1206 (3216 Metric)
DataSheet
Type
Infrared (IR)
Series
599
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Wavelength
850nm
Orientation
Top View
Part Status
Active
Manufacturer
Dialight
Mounting Type
Surface Mount
Viewing Angle
140°
Package / Case
1206 (3216 Metric)
Operating Temperature
-40°C ~ 85°C
Voltage - Forward (Vf) (Typ)
1.36V
Current - DC Forward (If) (Max)
100mA
Radiant Intensity (Ie) Min @ If
1mW/sr @ 100mA
| Attribute | Value |
|---|---|
| Type | Infrared (IR) |
| Series | 599 |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Wavelength | 850nm |
| Orientation | Top View |
| Part Status | Active |
| Manufacturer | Dialight |
| Mounting Type | Surface Mount |
| Viewing Angle | 140° |
| Package / Case | 1206 (3216 Metric) |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Forward (Vf) (Typ) | 1.36V |
| Current - DC Forward (If) (Max) | 100mA |
| Radiant Intensity (Ie) Min @ If | 1mW/sr @ 100mA |
