Step1: Product
Delta Electronics LNP-03A20WBCA
Image shown is a representation only
Manufacturer
Manufacturer No
LNP-03A20WBCA
Packaging
Bulk
Description
31V-42V 350MA IP20 ASSEMBLY FOR
Detailed Description
350mA 31 ~ 42V Constant Current LED Driver AC DC Converter Topology 1 Output
DataSheet
Type
Constant Current
Series
LNP-C (20W)
Ratings
IP20
Features
OCP, OTP, OVP, SCP
Topology
AC DC Converter
Packaging
Bulk
Efficiency
89.5%
Part Status
Obsolete
Manufacturer
Delta Electronics
Mounting Type
Chassis Mount
Power (Watts)
20 W
Approval Agency
CE
Size / Dimension
4.53" L x 1.77" W x 1.14" H (115.0mm x 45.0mm x 29.0mm)
Voltage - Output
31 ~ 42V
Number of Outputs
1
Termination Style
Screw Terminal
Voltage - Isolation
3.75 kV
DigiKey Programmable
Not Verified
Operating Temperature
-25°C ~ 55°C
Voltage - Input (Max)
264VAC
Voltage - Input (Min)
198VAC
Current - Output (Max)
350mA
| Attribute | Value |
|---|---|
| Type | Constant Current |
| Series | LNP-C (20W) |
| Ratings | IP20 |
| Features | OCP, OTP, OVP, SCP |
| Topology | AC DC Converter |
| Packaging | Bulk |
| Efficiency | 89.5% |
| Part Status | Obsolete |
| Manufacturer | Delta Electronics |
| Mounting Type | Chassis Mount |
| Power (Watts) | 20 W |
| Approval Agency | CE |
| Size / Dimension | 4.53" L x 1.77" W x 1.14" H (115.0mm x 45.0mm x 29.0mm) |
| Voltage - Output | 31 ~ 42V |
| Number of Outputs | 1 |
| Termination Style | Screw Terminal |
| Voltage - Isolation | 3.75 kV |
| DigiKey Programmable | Not Verified |
| Operating Temperature | -25°C ~ 55°C |
| Voltage - Input (Max) | 264VAC |
| Voltage - Input (Min) | 198VAC |
| Current - Output (Max) | 350mA |
