Step1: Product
Delta Electronics EFB1524VHG-EP
Image shown is a representation only
Manufacturer
Manufacturer No
EFB1524VHG-EP
Packaging
Box
Description
FAN AXIAL 172X50.8MM 24VDC WIRE
Detailed Description
Fan Tubeaxial 24VDC Rectangular/Rounded - 172mm L x 150mm H Ball 302.3 CFM (8.46m³/min) 4 Wire Leads
Datasheet
Mfr
Delta Electronics
RPM
4000 RPM
Noise
60.0dB(A)
Width
50.80mm
Series
EFB
Weight
1.9 lbs (861.8 g)
Air Flow
302.3 CFM (8.46m³/min)
Fan Type
Tubeaxial
Features
GR-487 (Salt Fog Protection), Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
Packaging
Box
Termination
4 Wire Leads
Bearing Type
Ball
Power (Watts)
24.48 W
Voltage Range
20.4 ~ 27.6VDC
Approval Agency
CE, CSA, UL, VDE
Static Pressure
0.937 in H2O (233.4 Pa)
Voltage - Rated
24VDC
Lifetime @ Temp.
80000 Hrs @ 40°C
Material - Blade
Plastic
Material - Frame
Aluminum
Size / Dimension
Rectangular/Rounded - 172mm L x 150mm H
Ingress Protection
IP56 - Dust Protected, Water Resistant
Base Product Number
EFB1524
Current Rating (Amps)
1.02A
Operating Temperature
14 ~ 158°F (-10 ~ 70°C)
| Attribute | Value |
|---|---|
| Mfr | Delta Electronics |
| RPM | 4000 RPM |
| Noise | 60.0dB(A) |
| Width | 50.80mm |
| Series | EFB |
| Weight | 1.9 lbs (861.8 g) |
| Air Flow | 302.3 CFM (8.46m³/min) |
| Fan Type | Tubeaxial |
| Features | GR-487 (Salt Fog Protection), Locked Rotor Protection, PWM Control, Speed Sensor (Tach) |
| Packaging | Box |
| Termination | 4 Wire Leads |
| Bearing Type | Ball |
| Power (Watts) | 24.48 W |
| Voltage Range | 20.4 ~ 27.6VDC |
| Approval Agency | CE, CSA, UL, VDE |
| Static Pressure | 0.937 in H2O (233.4 Pa) |
| Voltage - Rated | 24VDC |
| Lifetime @ Temp. | 80000 Hrs @ 40°C |
| Material - Blade | Plastic |
| Material - Frame | Aluminum |
| Size / Dimension | Rectangular/Rounded - 172mm L x 150mm H |
| Ingress Protection | IP56 - Dust Protected, Water Resistant |
| Base Product Number | EFB1524 |
| Current Rating (Amps) | 1.02A |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
