Step1: Product
Delta Electronics/Components 1008HS-273EKFS
Image shown is a representation only
Manufacturer
Manufacturer No
1008HS-273EKFS
Package
1008 (2520 Metric)
Packaging
Tape & Reel (TR)
Description
FIXED IND 27UH 180MA 3.5 OHM SMD
Detailed Description
27 µH Unshielded Drum Core, Wirewound Inductor 180 mA 3.5Ohm 1008 (2520 Metric)
DataSheet
Mfr
Delta Electronics/Components
Type
Drum Core, Wirewound
Series
1008HS
Q @ Freq
20 @ 2.52MHz
Packaging
Tape & Reel (TR)
Shielding
Unshielded
Tolerance
±10%
Inductance
27 µH
Part Status
Obsolete
Mounting Type
Surface Mount
Package / Case
1008 (2520 Metric)
Material - Core
Ferrite
Size / Dimension
0.115" L x 0.110" W (2.92mm x 2.79mm)
DC Resistance (DCR)
3.5Ohm
Current Rating (Amps)
180 mA
Height - Seated (Max)
0.083" (2.10mm)
Operating Temperature
-40°C ~ 85°C
Supplier Device Package
1008
Frequency - Self Resonant
17MHz
Inductance Frequency - Test
2.52 MHz
| Attribute | Value |
|---|---|
| Mfr | Delta Electronics/Components |
| Type | Drum Core, Wirewound |
| Series | 1008HS |
| Q @ Freq | 20 @ 2.52MHz |
| Packaging | Tape & Reel (TR) |
| Shielding | Unshielded |
| Tolerance | ±10% |
| Inductance | 27 µH |
| Part Status | Obsolete |
| Mounting Type | Surface Mount |
| Package / Case | 1008 (2520 Metric) |
| Material - Core | Ferrite |
| Size / Dimension | 0.115" L x 0.110" W (2.92mm x 2.79mm) |
| DC Resistance (DCR) | 3.5Ohm |
| Current Rating (Amps) | 180 mA |
| Height - Seated (Max) | 0.083" (2.10mm) |
| Operating Temperature | -40°C ~ 85°C |
| Supplier Device Package | 1008 |
| Frequency - Self Resonant | 17MHz |
| Inductance Frequency - Test | 2.52 MHz |
