Comchip Technology CMS10P10D-HF
Image shown is a representation only
Manufacturer
Manufacturer No
CMS10P10D-HF
Package
TO-252-3, DPAK (2 Leads + Tab), SC-63
Packaging
Tape & Reel (TR)
Description
MOSFET P-CH 100V 10A DPAK
Detailed Description
P-Channel 100 V 10A (Tc) 2W (Ta), 54W (Tc) Surface Mount TO-252 (DPAK)
DataSheet
Mfr
Comchip Technology
FET Type
P-Channel
Packaging
Tape & Reel (TR)
Vgs (Max)
±20V
Technology
MOSFET (Metal Oxide)
Part Status
Obsolete
Mounting Type
Surface Mount
Package / Case
TO-252-3, DPAK (2 Leads + Tab), SC-63
Vgs(th) (Max) @ Id
3V @ 250µA
Base Product Number
CMS10
Operating Temperature
-55°C ~ 150°C (TJ)
Rds On (Max) @ Id, Vgs
210mOhm @ 5A, 10V
Power Dissipation (Max)
2W (Ta), 54W (Tc)
Supplier Device Package
TO-252 (DPAK)
Gate Charge (Qg) (Max) @ Vgs
20 nC @ 10 V
Drain to Source Voltage (Vdss)
100 V
Input Capacitance (Ciss) (Max) @ Vds
1419 pF @ 25 V
Current - Continuous Drain (Id) @ 25°C
10A (Tc)
| Attribute | Value |
|---|---|
| Mfr | Comchip Technology |
| FET Type | P-Channel |
| Packaging | Tape & Reel (TR) |
| Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) |
| Part Status | Obsolete |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Vgs(th) (Max) @ Id | 3V @ 250µA |
| Base Product Number | CMS10 |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 210mOhm @ 5A, 10V |
| Power Dissipation (Max) | 2W (Ta), 54W (Tc) |
| Supplier Device Package | TO-252 (DPAK) |
| Gate Charge (Qg) (Max) @ Vgs | 20 nC @ 10 V |
| Drain to Source Voltage (Vdss) | 100 V |
| Input Capacitance (Ciss) (Max) @ Vds | 1419 pF @ 25 V |
| Current - Continuous Drain (Id) @ 25°C | 10A (Tc) |
