Step1: Product
Comchip Technology CDSPB40K-HF
Image shown is a representation only
Manufacturer
Manufacturer No
CDSPB40K-HF
Package
4-SMD
Packaging
Tape & Reel (TR)
Description
BRIDGE RECT 1PHASE 800V 4A 4-SPB
Detailed Description
Bridge Rectifier Single Phase 800 V Surface Mount 4-SPB
DataSheet
Series
Super Planar™
Packaging
Tape & Reel (TR)
Diode Type
Single Phase
Part Status
Obsolete
Manufacturer
Comchip Technology
Mounting Type
Surface Mount
Package / Case
4-SMD
Base Product Number
CDSPB40
Operating Temperature
-55°C ~ 150°C
Supplier Device Package
4-SPB
Voltage - Peak Reverse (Max)
800 V
Current - Reverse Leakage @ Vr
1 µA @ 800 V
Current - Average Rectified (Io)
4 A
Voltage - Forward (Vf) (Max) @ If
1 V @ 4 A
| Attribute | Value |
|---|---|
| Series | Super Planar™ |
| Packaging | Tape & Reel (TR) |
| Diode Type | Single Phase |
| Part Status | Obsolete |
| Manufacturer | Comchip Technology |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD |
| Base Product Number | CDSPB40 |
| Operating Temperature | -55°C ~ 150°C |
| Supplier Device Package | 4-SPB |
| Voltage - Peak Reverse (Max) | 800 V |
| Current - Reverse Leakage @ Vr | 1 µA @ 800 V |
| Current - Average Rectified (Io) | 4 A |
| Voltage - Forward (Vf) (Max) @ If | 1 V @ 4 A |
