Step1: Product
Central Semiconductor Corp CS65-70PB
Image shown is a representation only
Manufacturer
Manufacturer No
CS65-70PB
Package
TO-208AC, TO-65-3, Stud
Packaging
Box
Description
SCR 1.2KV 63A TO-65
Detailed Description
SCR 1.2 kV 63 A Standard Recovery Stud Mount TO-65
DataSheet
Series
CS65-70B
SCR Type
Standard Recovery
Packaging
Box
Part Status
Obsolete
Manufacturer
Central Semiconductor Corp
Mounting Type
Stud Mount
Package / Case
TO-208AC, TO-65-3, Stud
Voltage - Off State
1.2 kV
Operating Temperature
-65°C ~ 125°C (TJ)
Supplier Device Package
TO-65
Current - Hold (Ih) (Max)
200 mA
Current - Off State (Max)
6 mA
Voltage - On State (Vtm) (Max)
3 V
Current - Gate Trigger (Igt) (Max)
100 mA
Current - On State (It (AV)) (Max)
40 A
Voltage - Gate Trigger (Vgt) (Max)
3 V
Current - On State (It (RMS)) (Max)
63 A
Current - Non Rep. Surge 50, 60Hz (Itsm)
1000A @ 60Hz
| Attribute | Value |
|---|---|
| Series | CS65-70B |
| SCR Type | Standard Recovery |
| Packaging | Box |
| Part Status | Obsolete |
| Manufacturer | Central Semiconductor Corp |
| Mounting Type | Stud Mount |
| Package / Case | TO-208AC, TO-65-3, Stud |
| Voltage - Off State | 1.2 kV |
| Operating Temperature | -65°C ~ 125°C (TJ) |
| Supplier Device Package | TO-65 |
| Current - Hold (Ih) (Max) | 200 mA |
| Current - Off State (Max) | 6 mA |
| Voltage - On State (Vtm) (Max) | 3 V |
| Current - Gate Trigger (Igt) (Max) | 100 mA |
| Current - On State (It (AV)) (Max) | 40 A |
| Voltage - Gate Trigger (Vgt) (Max) | 3 V |
| Current - On State (It (RMS)) (Max) | 63 A |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 1000A @ 60Hz |
