Step1: Product
California Micro Devices CM1423-03CP
Image shown is a representation only
Manufacturer
Manufacturer No
CM1423-03CP
Package
20-WFBGA, WLCSP
Packaging
Bulk
Description
FILTER RC(PI) 100 OHMS ESD SMD
Detailed Description
RC (Pi) EMI Filter 2nd Order Low Pass 6 Channel R = 100Ohms, C = 12pF 20-WFBGA, WLCSP
Datasheet
Type
Low Pass
Height
0.020" (0.51mm)
Values
R = 100Ohms, C = 12pF
Packaging
Bulk
Technology
RC (Pi)
Applications
Data Lines for Mobile Devices
Filter Order
2nd
Manufacturer
California Micro Devices
Mounting Type
Surface Mount
ESD Protection
Yes
Package / Case
20-WFBGA, WLCSP
Size / Dimension
0.157" L x 0.057" W (4.00mm x 1.46mm)
Attenuation Value
25dB @ 1GHz
Number of Channels
6
Base Product Number
CM1423
Operating Temperature
-40°C ~ 85°C
Center / Cutoff Frequency
145MHz (Cutoff)
Resistance - Channel (Ohms)
100
| Attribute | Value |
|---|---|
| Type | Low Pass |
| Height | 0.020" (0.51mm) |
| Values | R = 100Ohms, C = 12pF |
| Packaging | Bulk |
| Technology | RC (Pi) |
| Applications | Data Lines for Mobile Devices |
| Filter Order | 2nd |
| Manufacturer | California Micro Devices |
| Mounting Type | Surface Mount |
| ESD Protection | Yes |
| Package / Case | 20-WFBGA, WLCSP |
| Size / Dimension | 0.157" L x 0.057" W (4.00mm x 1.46mm) |
| Attenuation Value | 25dB @ 1GHz |
| Number of Channels | 6 |
| Base Product Number | CM1423 |
| Operating Temperature | -40°C ~ 85°C |
| Center / Cutoff Frequency | 145MHz (Cutoff) |
| Resistance - Channel (Ohms) | 100 |
