Step1: Product
Bourns Inc. SRF0703-102M
Image shown is a representation only
Manufacturer
Manufacturer No
SRF0703-102M
Date Code
22+
Quantity
400
Availability
In Stock
Package
Nonstandard
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
INDUCT ARRAY 2 COIL 1MH SMD
Detailed Description
Shielded 2 Coil Inductor Array 4 mH Inductance - Connected in Series 1 mH Inductance - Connected in Parallel 6.11Ohm Max DC Resistance (DCR) - Parallel 260 mA Nonstandard
Datasheet
Height
0.142" (3.60mm)
Series
SRF0703
Packaging
Tape & Reel (TR); Cut Tape (CT)
Shielding
Shielded
Tolerance
±20%
Manufacturer
Bourns Inc.
Mounting Type
Surface Mount
Package / Case
Nonstandard
Number of Coils
2
Size / Dimension
0.299" L x 0.299" W (7.60mm x 7.60mm)
Base Product Number
SRF0703
Operating Temperature
-40°C ~ 125°C
Current Rating - Series
128 mA
Current Rating - Parallel
260 mA
Current Saturation - Series
130 mA
DC Resistance (DCR) - Series
24.42Ohm Max
Current Saturation - Parallel
250 mA
DC Resistance (DCR) - Parallel
6.11Ohm Max
Inductance - Connected In Series
4 mH
Inductance - Connected In Parallel
1 mH
| Attribute | Value |
|---|---|
| Height | 0.142" (3.60mm) |
| Series | SRF0703 |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Shielding | Shielded |
| Tolerance | ±20% |
| Manufacturer | Bourns Inc. |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Number of Coils | 2 |
| Size / Dimension | 0.299" L x 0.299" W (7.60mm x 7.60mm) |
| Base Product Number | SRF0703 |
| Operating Temperature | -40°C ~ 125°C |
| Current Rating - Series | 128 mA |
| Current Rating - Parallel | 260 mA |
| Current Saturation - Series | 130 mA |
| DC Resistance (DCR) - Series | 24.42Ohm Max |
| Current Saturation - Parallel | 250 mA |
| DC Resistance (DCR) - Parallel | 6.11Ohm Max |
| Inductance - Connected In Series | 4 mH |
| Inductance - Connected In Parallel | 1 mH |
