Step1: Product
Assmann WSW Components A-HDF 78 PP/Z-UNC1
Image shown is a representation only
Manufacturer
Manufacturer No
A-HDF 78 PP/Z-UNC1
Packaging
Tray
Description
CONN D-SUB HD RCPT 78P VERT SLDR
Detailed Description
78 Position D-Sub, High Density Receptacle, Female Sockets Connector
DataSheet
Mfr
Assmann WSW Components
Color
Black
Packaging
Tray
Part Status
Active
Termination
Solder
Contact Type
Signal
Mounting Type
Through Hole
Connector Type
Receptacle, Female Sockets
Contact Finish
Gold
Flange Feature
Mating Side, Female Screwlock (4-40)
Number of Rows
4
Voltage Rating
250VAC
Connector Style
D-Sub, High Density
Contact Material
Copper Alloy
Dielectric Material
Polybutylene Terephthalate (PBT), Glass Filled
Number of Positions
78
Current Rating (Amps)
3A
Operating Temperature
-55°C ~ 105°C
Shell Material, Finish
Steel, Tin Plated
Contact Finish Thickness
Flash
Material Flammability Rating
UL94 V-0
Shell Size, Connector Layout
5 (DD, D) High Density
| Attribute | Value |
|---|---|
| Mfr | Assmann WSW Components |
| Color | Black |
| Packaging | Tray |
| Part Status | Active |
| Termination | Solder |
| Contact Type | Signal |
| Mounting Type | Through Hole |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Flange Feature | Mating Side, Female Screwlock (4-40) |
| Number of Rows | 4 |
| Voltage Rating | 250VAC |
| Connector Style | D-Sub, High Density |
| Contact Material | Copper Alloy |
| Dielectric Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Number of Positions | 78 |
| Current Rating (Amps) | 3A |
| Operating Temperature | -55°C ~ 105°C |
| Shell Material, Finish | Steel, Tin Plated |
| Contact Finish Thickness | Flash |
| Material Flammability Rating | UL94 V-0 |
| Shell Size, Connector Layout | 5 (DD, D) High Density |
