Analog Devices Inc. ADL5801ACPZ-R7
Image shown is a representation only
Manufacturer
Manufacturer No
ADL5801ACPZ-R7
Quantity
215
Availability
In Stock
Package
24-VFQFN Exposed Pad, CSP
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
IC MXR 10MHZ-6GHZ UP/DWN 24LFCSP
Detailed Description
RF Mixer IC Cellular Up/Down Converter 10MHz ~ 6GHz 24-LFCSP-VQ (4x3.75)
DataSheet
Gain
1.8dB
RF Type
Cellular
Frequency
10MHz ~ 6GHz
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Part Status
Active
Manufacturer
Analog Devices Inc.
Noise Figure
9.75dB
Mounting Type
Surface Mount
Package / Case
24-VFQFN Exposed Pad, CSP
Current - Supply
130mA
Number of Mixers
1
Voltage - Supply
4.75V ~ 5.25V
Base Product Number
ADL5801
Secondary Attributes
Up/Down Converter
Supplier Device Package
24-LFCSP-VQ (4x3.75)
| Attribute | Value |
|---|---|
| Gain | 1.8dB |
| RF Type | Cellular |
| Frequency | 10MHz ~ 6GHz |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Part Status | Active |
| Manufacturer | Analog Devices Inc. |
| Noise Figure | 9.75dB |
| Mounting Type | Surface Mount |
| Package / Case | 24-VFQFN Exposed Pad, CSP |
| Current - Supply | 130mA |
| Number of Mixers | 1 |
| Voltage - Supply | 4.75V ~ 5.25V |
| Base Product Number | ADL5801 |
| Secondary Attributes | Up/Down Converter |
| Supplier Device Package | 24-LFCSP-VQ (4x3.75) |
