Step1: Product
Analog Devices Inc./Maxim Integrated MAX20040ATPB/VY+T
Image shown is a representation only
Manufacturer
Manufacturer No
MAX20040ATPB/VY+T
Package
20-WFQFN Exposed Pad
Packaging
Tape & Reel (TR)
Description
IC REG BUCK BST PROG 20TQFN
Detailed Description
Buck-Boost Switching Regulator IC Positive Programmable (Fixed) 1 Output 1.2A 20-WFQFN Exposed Pad
Mfr
Analog Devices Inc./Maxim Integrated
Grade
Automotive
Function
Step-Up/Step-Down
Topology
Buck-Boost
Packaging
Tape & Reel (TR)
Output Type
Programmable (Fixed)
Part Status
Obsolete
Mounting Type
Surface Mount, Wettable Flank
Qualification
AEC-Q100
Package / Case
20-WFQFN Exposed Pad
Current - Output
1.2A
Number of Outputs
1
Base Product Number
MAX20040
Output Configuration
Positive
Frequency - Switching
2.2MHz
Operating Temperature
-40°C ~ 125°C
Synchronous Rectifier
Yes
Voltage - Input (Max)
36V
Voltage - Input (Min)
2V
Voltage - Output (Max)
15V
Supplier Device Package
20-TQFN-EP (4x4)
| Attribute | Value |
|---|---|
| Mfr | Analog Devices Inc./Maxim Integrated |
| Grade | Automotive |
| Function | Step-Up/Step-Down |
| Topology | Buck-Boost |
| Packaging | Tape & Reel (TR) |
| Output Type | Programmable (Fixed) |
| Part Status | Obsolete |
| Mounting Type | Surface Mount, Wettable Flank |
| Qualification | AEC-Q100 |
| Package / Case | 20-WFQFN Exposed Pad |
| Current - Output | 1.2A |
| Number of Outputs | 1 |
| Base Product Number | MAX20040 |
| Output Configuration | Positive |
| Frequency - Switching | 2.2MHz |
| Operating Temperature | -40°C ~ 125°C |
| Synchronous Rectifier | Yes |
| Voltage - Input (Max) | 36V |
| Voltage - Input (Min) | 2V |
| Voltage - Output (Max) | 15V |
| Supplier Device Package | 20-TQFN-EP (4x4) |
