Step1: Product
ams-OSRAM USA INC. AS5147-HTSM
Image shown is a representation only
Manufacturer
Manufacturer No
AS5147-HTSM
Quantity
8
Availability
In Stock
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
ENCODER MAG COMMUTATION SMD TAB
Detailed Description
Rotary Encoder Magnetic Programmable Commutation, PWM, SPI, Quadrature with index (Incremental)
Datasheet
Grade
Automotive
Detent
No
Packaging
Tape & Reel (TR); Cut Tape (CT)
Output Type
Commutation, PWM, SPI, Quadrature with index (Incremental)
Encoder Type
Magnetic
Manufacturer
ams-OSRAM USA INC.
Actuator Type
External Magnet, Not Included
Mounting Type
Surface Mount
Qualification
AEC-Q100
Built in Switch
No
Voltage - Supply
3V ~ 3.6V, 4.5V ~ 5.5V
Termination Style
SMD (SMT) Tab
Base Product Number
AS5147
DigiKey Programmable
Not Verified
Pulses per Revolution
Programmable
| Attribute | Value |
|---|---|
| Grade | Automotive |
| Detent | No |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Output Type | Commutation, PWM, SPI, Quadrature with index (Incremental) |
| Encoder Type | Magnetic |
| Manufacturer | ams-OSRAM USA INC. |
| Actuator Type | External Magnet, Not Included |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q100 |
| Built in Switch | No |
| Voltage - Supply | 3V ~ 3.6V, 4.5V ~ 5.5V |
| Termination Style | SMD (SMT) Tab |
| Base Product Number | AS5147 |
| DigiKey Programmable | Not Verified |
| Pulses per Revolution | Programmable |
