Step1: Product
American High Voltage 580046k
Image shown is a representation only
Manufacturer
Manufacturer No
580046k
Packaging
Bulk
Description
SF-12V
Detailed Description
Enclosed, High Voltage DC DC Converter 1 Output 0 ~ 1200V 8mA 28V Input
DataSheet
Type
Enclosed, High Voltage
Series
SF (10W)
Packaging
Bulk
Efficiency
60%
Part Status
Active
Manufacturer
American High Voltage
Mounting Type
Chassis Mount
Power (Watts)
10W
Size / Dimension
4.00" L x 2.00" W x 0.81" H (101.6mm x 50.8mm x 20.6mm)
Number of Outputs
1
Voltage - Output 1
0 ~ 1200V
Voltage - Isolation
5 kV
Operating Temperature
-40°C ~ 71°C
Voltage - Input (Max)
28V
Current - Output (Max)
8mA
| Attribute | Value |
|---|---|
| Type | Enclosed, High Voltage |
| Series | SF (10W) |
| Packaging | Bulk |
| Efficiency | 60% |
| Part Status | Active |
| Manufacturer | American High Voltage |
| Mounting Type | Chassis Mount |
| Power (Watts) | 10W |
| Size / Dimension | 4.00" L x 2.00" W x 0.81" H (101.6mm x 50.8mm x 20.6mm) |
| Number of Outputs | 1 |
| Voltage - Output 1 | 0 ~ 1200V |
| Voltage - Isolation | 5 kV |
| Operating Temperature | -40°C ~ 71°C |
| Voltage - Input (Max) | 28V |
| Current - Output (Max) | 8mA |
