Step1: Product
Allegro MicroSystems ACS712ELCTR-05B-T
Image shown is a representation only
Manufacturer
Manufacturer No
ACS712ELCTR-05B-T
Date Code
1627
Quantity
18
Availability
In Stock
Package
8-SOIC (0.154", 3.90mm Width)
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
CURRENT SENSOR HE/OL 5A 8-SOIC
Detailed Description
Current Sensor 5A 1 Channel Hall Effect, Open Loop Bidirectional 8-SOIC (0.154", 3.90mm Width)
Datasheet
Mfr
Allegro MicroSystems
Output
Ratiometric, Voltage
Accuracy
±1.5%
Frequency
DC ~ 80kHz
Linearity
±1.5%
Packaging
Tape & Reel (TR); Cut Tape (CT)
Sensitivity
185mV/A
Sensor Type
Hall Effect, Open Loop
Polarization
Bidirectional
For Measuring
AC/DC
Mounting Type
Surface Mount
Response Time
5µs
Package / Case
8-SOIC (0.154", 3.90mm Width)
Voltage - Supply
5V
Current - Sensing
5A
Number of Channels
1
Base Product Number
ACS712
Operating Temperature
-40°C ~ 85°C
Current - Supply (Max)
13mA
Supplier Device Package
8-SOIC
| Attribute | Value |
|---|---|
| Mfr | Allegro MicroSystems |
| Output | Ratiometric, Voltage |
| Accuracy | ±1.5% |
| Frequency | DC ~ 80kHz |
| Linearity | ±1.5% |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Sensitivity | 185mV/A |
| Sensor Type | Hall Effect, Open Loop |
| Polarization | Bidirectional |
| For Measuring | AC/DC |
| Mounting Type | Surface Mount |
| Response Time | 5µs |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Voltage - Supply | 5V |
| Current - Sensing | 5A |
| Number of Channels | 1 |
| Base Product Number | ACS712 |
| Operating Temperature | -40°C ~ 85°C |
| Current - Supply (Max) | 13mA |
| Supplier Device Package | 8-SOIC |
