Step1: Product
aimtec AM2D-0512DZ
Image shown is a representation only
Manufacturer
Manufacturer No
AM2D-0512DZ
Package
7-SIP Module, 5 Leads
Packaging
Tube
Description
DC DC CONVERTER +/-12V 2W
Detailed Description
Isolated Module DC DC Converter 2 Output 12V -12V 83mA, 83mA 4.5V - 5.5V Input
Mfr
aimtec
Type
Isolated Module
Series
AM2D-Z
Packaging
Tube
Efficiency
78%
Part Status
Active
Applications
ITE (Commercial)
Mounting Type
Through Hole
Power (Watts)
2 W
Package / Case
7-SIP Module, 5 Leads
Approval Agency
CE
Size / Dimension
0.76" L x 0.24" W x 0.39" H (19.5mm x 6.0mm x 10.0mm)
Number of Outputs
2
Voltage - Output 1
12V
Voltage - Output 2
-12V
Base Product Number
AM2D
Voltage - Isolation
1 kV
Operating Temperature
-40°C ~ 85°C
Voltage - Input (Max)
5.5V
Voltage - Input (Min)
4.5V
Current - Output (Max)
83mA, 83mA
Supplier Device Package
7-SIP
| Attribute | Value |
|---|---|
| Mfr | aimtec |
| Type | Isolated Module |
| Series | AM2D-Z |
| Packaging | Tube |
| Efficiency | 78% |
| Part Status | Active |
| Applications | ITE (Commercial) |
| Mounting Type | Through Hole |
| Power (Watts) | 2 W |
| Package / Case | 7-SIP Module, 5 Leads |
| Approval Agency | CE |
| Size / Dimension | 0.76" L x 0.24" W x 0.39" H (19.5mm x 6.0mm x 10.0mm) |
| Number of Outputs | 2 |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | -12V |
| Base Product Number | AM2D |
| Voltage - Isolation | 1 kV |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Input (Max) | 5.5V |
| Voltage - Input (Min) | 4.5V |
| Current - Output (Max) | 83mA, 83mA |
| Supplier Device Package | 7-SIP |
