Step1: Product
Aces Connectors 50208-01201-001
Image shown is a representation only
Manufacturer
Manufacturer No
50208-01201-001
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
12P, 0.8MM WTB IDT CONN., SMT S/
Detailed Description
Connector Header Surface Mount, Right Angle 12 position 0.031" (0.80mm)
DataSheet
Mfr
Aces Connectors
Style
Board to Cable/Wire
Series
50208
Features
Solder Retention
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Shrouding
Shrouded - 4 Wall
Part Status
Active
Termination
Solder
Contact Type
Male Pin
Contact Shape
Rectangular
Mounting Type
Surface Mount, Right Angle
Connector Type
Header
Fastening Type
Push-Pull
Number of Rows
1
Pitch - Mating
0.031" (0.80mm)
Voltage Rating
36VAC
Contact Material
Phosphor Bronze
Insulation Color
Black
Insulation Height
0.067" (1.70mm)
Insulation Material
Plastic
Number of Positions
12
Contact Finish - Post
Gold
Current Rating (Amps)
0.7A
Operating Temperature
-25°C ~ 85°C
Contact Finish - Mating
Gold
Number of Positions Loaded
All
Material Flammability Rating
UL94 V-0
Contact Finish Thickness - Post
Flash
Contact Finish Thickness - Mating
Flash
| Attribute | Value |
|---|---|
| Mfr | Aces Connectors |
| Style | Board to Cable/Wire |
| Series | 50208 |
| Features | Solder Retention |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Shrouding | Shrouded - 4 Wall |
| Part Status | Active |
| Termination | Solder |
| Contact Type | Male Pin |
| Contact Shape | Rectangular |
| Mounting Type | Surface Mount, Right Angle |
| Connector Type | Header |
| Fastening Type | Push-Pull |
| Number of Rows | 1 |
| Pitch - Mating | 0.031" (0.80mm) |
| Voltage Rating | 36VAC |
| Contact Material | Phosphor Bronze |
| Insulation Color | Black |
| Insulation Height | 0.067" (1.70mm) |
| Insulation Material | Plastic |
| Number of Positions | 12 |
| Contact Finish - Post | Gold |
| Current Rating (Amps) | 0.7A |
| Operating Temperature | -25°C ~ 85°C |
| Contact Finish - Mating | Gold |
| Number of Positions Loaded | All |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Post | Flash |
| Contact Finish Thickness - Mating | Flash |
